Metrel MI 3114 Standard PV CAT II 1500 V Tester Kit

DescriptionMetrel MI 3114 PV Tester Standard SetThe Metrel MI 3114 PV Tester Standard Set is an advanced testing solution designed to meet the stringent requirements of low voltage electrical installations and photovoltaic (PV) systems, ensuring compliance with critical standards like IEC/EN 62446-1. It supports comprehensive testing for PV systems with a maximum voltage of 1500 V and a short circuit current of 40 A.This tester includes capabilities for:1500 V insulation resistance of stringsContinuity of PE conductorsPolarity testingIsc and Uoc measurementsCalculation of STC (Standard Test Conditions) values and comparison with nominal data.The MI 3114 is ideal for contractors, maintainers, and inspectors certified in EISinsp and EISc Competences, aligning with standards for building LV installations such as IEC/EN 60364, IEC/EN 61557, and IEC/EN 62446-1. Key Features:Auto test for Category 1 tests: Simplifies testing with a single button operation.Wireless remote unit: Measures irradiation and cell temperature in real-time via Wi-Fi.Memory organizer and PV module database handler: Efficiently manage data and perform searches on single or grouped measurements.Error correction: Modify incorrect parameters even after executing measurements.PC software (Metrel ES Manager): Enables preparation of measurement structures, data upload/download, result review, and the creation of professional reports.Standards Compliance:Photovoltaic Systems: IEC/EN 62446, EN 62466-1, EN 62466-2Instrument Safety: IEC/EN 61010-1, IEC/EN 61010-031, IEC/EN 61010-2-030Electrical Installations: IEC/EN 60364 series, IEC/EN 61557 series (including 61557-2 for insulation resistance)EMC Safety: IEC/EN 61326-1What’s Included in the MI 3114 Standard Set:Instrument MI 3114A 1790 BLU: Test lead, Blue, 3m, 2.5mm²A 1790 RED: Test lead, Red, 3m, 2.5mm²A 1792: Test lead, Green, 3m, 0.75mm²S 2146: Set PV MC4 to banana adapters, 1500 VA 1509: Test lead, Black, 50m, 0.75mm²A 1012: Test lead, Green, 4m, 0.75mm²A 1309: Crocodile clip, GreenA 1014: Test probe, BlackA 1015: Test probe, BlueA 1016: Test probe, RedA 1727: Communication cable, 1m, USB type B/AA 1728: Power cable, 2m, 3×0.75mm²A 1551: Soft padded carrying bag, Size: LSW 1201: Metrel ES Manager (MESM) softwareP 1000-EU: License key basicCalibration certificate for MI 3114User ManualApplications:Testing low voltage photovoltaic installationsEvaluating renewable energy sourcesValidating STC values and PV panel performanceInspections in special locations
