BX1100C-IN Technical Specifications (1100VA/660W – Line Interactive UPS) Output Specifications Parameter Details Output Capacity (VA) 1100 VA Output Capacity (W) 660 W UPS Topology Line Interactive Output Voltage 230 V AC Output Frequency 47–63 Hz (Sync to Mains) Transfer Time 10–12 ms Typical Output Waveform Type Stepped Approximation to Sine Wave Maximum Configurable Power 660 W / 1100 VA Input Specifications Parameter Details Input Voltage 230 V AC Input Voltage Range 145 – 290 V Input Frequency 47–63 Hz Input Connection Type India 3-Pin 6A Plug Automatic Voltage Regulation (AVR) Yes Switching Current Capacity 7 A Batteries & Runtime Parameter Details Battery Type Maintenance-Free Sealed Lead-Acid Battery Battery Configuration 2 × 12V, 7.2Ah Internal Batteries Battery Backup Support Yes Typical Recharge Time Approx. 6 Hours Battery Charge Power 29 W Battery Volt-Amp-Hour Capacity 173 VAh Full Load Runtime Approx. 3.5 Minutes Half Load Runtime Approx. 14 Minutes Quarter Load Runtime Approx. 35 Minutes Communication & Management Parameter Details LED Status Indicators Yes Audible Alarm Yes Battery Charging Indicator Yes Automatic Self-Test Yes Cold Start Capability Yes Battery Saver Function Yes Physical Specifications Parameter Details Height 282 mm Width 132 mm Depth 259 mm Net Weight 8.98 kg Product Color Black Form Factor Tower Environmental Specifications Parameter Details Operating Temperature 0°C to 40°C Relative Humidity 0% to 95% Non-Condensing Operating Elevation Up to 3000 m Other Specifications Parameter Details Product Series APC Back-UPS BX Series Model Number BX1100C-IN Brand APC by Schneider Electric Technology Line Interactive UPS with AVR Warranty 1 Year Repair or Replace Application Type Home & Office Power Protection Product Overview The APC BX1100C-IN Back-UPS delivers dependable battery backup and surge protection for computers, networking devices, gaming consoles, and essential electronics. Equipped with Automatic Voltage Regulation (AVR), it automatically corrects voltage fluctuations without using battery power, helping extend battery life and improve performance. With 1100VA/660W capacity, five Indian power sockets, built-in maintenance-free batteries, and generator compatibility, the BX1100C-IN provides reliable protection against unexpected power interruptions and unstable electrical conditions.
